Extended Servo Weighing & Mixing Feeder
D-BATCH-X
Extended Servo Weighing & Mixing Feeder
This extended weighing and weight-reducing feeder is built on the economical model, adding screw feeding modules on both sides and a secondary mixing module at the bottom. It solves accuracy errors caused by special material densities and particle states. With servo motor control and precision-cast screw barrels, it achieves higher ratio accuracy for complex materials (types 7 and 8), supports a wider range of formulas, and provides better raw material mixing through the secondary mixing device.
KG/H
Get Quote
Introduction

The integrated weighing and weight-reducing feeding machine - extended type, is an enhanced version based on the economical model, featuring additional screw feeding modules on both sides and a secondary mixing module at the bottom. It is designed to address the issue of accuracy errors in the batching of materials with special densities and specific particle states. Through servo motor control and precision casting of the screw barrels for transportation, it achieves higher precision ratios for the seventh and eighth types of materials, providing a wider range of formula combinations. Additionally, an extra secondary mixing device is added to achieve a better raw material mixing effect.

Features
  • The control technology in Europe is advanced, stable and reliable, with a low failure rate;
  • Extrusion control, with an accuracy of ±0.3%;
  • Precise proportioning, with an accuracy of ±0.5%;
  • Reverse stirring, ensuring uniform mixing;
  • Template-based design, economical and efficient;
  • Both sides equipped with servo metering motors, with low power consumption and high-precision control;
  • Energy-saving and environmentally friendly, effectively saving raw materials;
  • Industrial 4.0 platform, professional production management.
Specifications

Model

Output

Raw material unit

D-BATCH-X-200

200Kg/h

7,8

D-BATCH-X-400

400Kg/h

7,8

D-BATCH-X-800

800Kg/h

7,8

Options
Our Advantages
100% Factory Tested
Each component undergoes dedicated, specialized testing to ensure zero-defect delivery.
Reliable Quality Assurance
All accessories come with a one-year standard warranty, reflecting our commitment to product quality.
Strict Supply Chain Management
By partnering with industry-leading suppliers, we ensure the exceptional quality and stable performance of raw materials and core components.
Independently developed weighing algorithm
-- Deep customized development capabilities
Our self-developed algorithm supports the integration of various weighing devices, whether it is static weighing or dynamic weighing, it can provide accurate weight loss calculation. At the same time, the software has powerful data processing and real-time monitoring functions, which can identify abnormalities in time and ensure smooth production. In addition, the system can be customized according to customer needs, providing flexible interfaces and expansion functions to adapt to different business scenarios.
check the details
why
15%
Technical Staff
Highly skilled engineering team
20%
R&D Investment
Of annual profit reinvested
30+
Tech Patents
Core intellectual property rights
FAQs
What is the accuracy of the DEFINITI feeder?

Our loss-in-weight feeders achieve accuracy of ±0.3% to ±0.5%, while the volumetric series achieves ±1%. This is ensured through three key factors: first, the use of high-precision sensors from Siemens/Schneider; second, proprietary algorithm software for real-time compensation; and third, pre-shipment calibration testing of materials in a temperature-controlled laboratory.

What is the difference between the Ultimate and Economical models?

The Ultimate model is the highest precision model, with a precision of ±0.3%.

What is the difference between the Ultimate and Economical models?

The Ultimate model is the highest precision model, with a precision of ±0.3%.
