The integrated weighing and weight-reducing feeding machine - extended type, is an enhanced version based on the economical model, featuring additional screw feeding modules on both sides and a secondary mixing module at the bottom. It is designed to address the issue of accuracy errors in the batching of materials with special densities and specific particle states. Through servo motor control and precision casting of the screw barrels for transportation, it achieves higher precision ratios for the seventh and eighth types of materials, providing a wider range of formula combinations. Additionally, an extra secondary mixing device is added to achieve a better raw material mixing effect.
- The control technology in Europe is advanced, stable and reliable, with a low failure rate;
- Extrusion control, with an accuracy of ±0.3%;
- Precise proportioning, with an accuracy of ±0.5%;
- Reverse stirring, ensuring uniform mixing;
- Template-based design, economical and efficient;
- Both sides equipped with servo metering motors, with low power consumption and high-precision control;
- Energy-saving and environmentally friendly, effectively saving raw materials;
- Industrial 4.0 platform, professional production management.
|
Model |
Output |
Raw material unit |
|
D-BATCH-X-200 |
200Kg/h |
7,8 |
|
D-BATCH-X-400 |
400Kg/h |
7,8 |
|
D-BATCH-X-800 |
800Kg/h |
7,8 |
